MAXICHARGER AC
Dual Wall Enclosure SINGLE PHASE
WALL MOUNTED CHARGER
MaxiCharger AC Dual Wall Enclosure SINGLE PHASE
The MaxiCharger AC dual wall enclosure is a wall mounted powder coated steel enclosure for side by side housing of two MaxiCharger single outlet, universal Type 2 socket smart EV chargers.
The MaxiCharger AC charge points are OCPP 1.6 compliant, have built in PME fault detection (PEN protection), IP54 weather rating, 4G connectivity options, static load management and dynamic load balancing capabilities.
| Technical specification | |
|---|---|
| Charging type | Mode 3, Type 2 |
| Charging power | 7.4 kW |
| Rated current | 32 A/16 A |
| Rated frequency | 50 Hz |
| Input/output voltage | 230 V±10%, L1, N, PE |
| Network type | TT, TN |
| RCB | Integrated 6mA DC +30mA AC leakage detection |
| Protection | Overcurrent, overvoltage, undervoltage, ground fault including DC residual current protection, integrated surge protection |
| PME fault detection | Incorporated within the unit |
POWERING UP TOGETHER
Benefits
99% product reliability
Easy installation
Flexible solutions
Universal compatibility
Smart app controlled
3 year warranty
Maxicharger AC Dual Wall Enclosure Single Phase
A TRUSTED SOLUTION FOR DOMESTIC & COMMERCIAL EV CHARGING
- Fully compliant with the Electric Vehicles (Smart Charge Point) Regulations 2021
- PME fault detection incorporated (PEN protection)
- 7.4kW single socket output with/without 4G
- Single phase connection
- OCPP 1.6 compliant
- Smart app or cloud management software
- Dynamic load balancing and static load management capabilities
- OZEV approved
- 3 year warranty
Fully compliant with the Electric Vehicles (Smart Charge Point) Regulations 2021
PME fault detection incorporated (PEN protection)
7.4kW single socket output with/without 4G option
Single phase connection
OCPP 1.6 compliant
Smart app or cloud management software
Dynamic load balancing and static load management capabilities
OZEV approved
3 year warranty
